Description
Parameters
| Installation size | Micro (19mm) |
| Dimensions (Length * Width * Height) | 19x19 mm |
| Input voltage | 4.5 - 25 V |
| Internal microphone | no |
| resolution | 1200 TVL |
| Sensor type | Sony 1/3" CMOS |
| TV system | NTSC / PAL switchable |
| Weight | 4,5 g |
| Shutter Speed | PAL 1/25~1/10000 sec; NTSC 1/30~1/10000 sec |
| Video Output | CVBS Analog Signal |
| FOV | 16:9 FOV-H:125° FOV-D:145° |
| Shutter Speed | Auto |
| Minimum Illumination | 0.01Lux |
| White Balance | Auto |
| DNR | 3DNR |
| WDR | 90dB |
| DAY/NIGHT | EXT/Auto/Color/B&W |
| Flight OSD | No |
| Input Voltage | 4.5V~25V |
| Language | ENGLISH / 中文 / 繁体 / PYCCKNN / ESPANOL / FRANCAIS / POLSKI / ITALIANO / PORTUGUES / 日本语 / 한국어 / EAAHNIKA |
| Working Temperature | -10°~50°C RH90% MAX |
| Working Humidiy | 20~80% |
| Storage Temperature | -20°~70°C |
Package contents
1 x Cam
1 x Extension Bracket
1 x 2pin OSD Cable
2 x Servo Silicon Cable
1 x OSD Board
M2 Screws
1 x Extension Bracket
1 x 2pin OSD Cable
2 x Servo Silicon Cable
1 x OSD Board
M2 Screws
