Parameters
voltage | 4-6 cell (14.8V-22.2V) |
Overall Dimension | Φ26.2×15.3mm |
prop mounting shaft diameter | 1.5mm |
Installation hole position | 12×12mm,M2 |
Prop | 3.5inch~5inch |
Bearing:7*3*3 | |
Shaft Diameter | 3.0mm |
Lead Wire Size:24AWG×150mm | |
slots/poles | 12N14P |
Magnet Wire | 240℃ Enameled Wire |
Stator Diamter:20mm | |
Stator Height | 4mm |
Rated Voltage | 4~6S (16.8V~25.2V) |
Peak Current | 17.52A |
ldle Current:10V/0.3~0.8A | |
Maximum Power | 418.1W |
Internal Resistance:210mΩ | |
Weight | 16.3g |
